护套对高速永磁电机转子损耗影响研究数据

通过理论分析和仿真建模，得到了护套对高速永磁电机转子损耗影响研究数据，该数据集记录了组合护套各部分涡流损耗，具体包括组合护套结构示意图，仿真模型图，0.1mm转子内铜层各部分涡流损耗及铜层厚度变化对转子各部分影响图。数据类型主要包括组合护套不加铜层转子各部分涡流损耗，组合护套加0.1mm内铜层各部分涡流损耗，组合护套加0.1mm中间铜层各部分涡流损耗，铜层厚度变化转子各部分涡流损耗。Research data on the effect of protective sleeves on rotor losses of high-speed permanent magnet motors was obtained through theoretical analysis and simulation modeling. This dataset records the eddy current losses of each component of the composite protective sleeve, and specifically includes the structural schematic diagram of the composite protective sleeve, the simulation model diagram, the eddy current losses of each part of the rotor with a 0.1mm inner copper layer, and the diagrams illustrating the impact of copper layer thickness variation on each part of the rotor. The main data types are as follows: eddy current losses of each part of the rotor without a copper layer in the composite protective sleeve; eddy current losses of each part of the rotor with a 0.1mm inner copper layer in the composite protective sleeve; eddy current losses of each part of the rotor with a 0.1mm middle copper layer in the composite protective sleeve; and eddy current losses of each part of the rotor under varying copper layer thicknesses.

搜集汇总

背景与挑战

背景概述

该数据集基于理论分析和仿真建模，研究了护套对高速永磁电机转子损耗的影响，主要记录了组合护套各部分涡流损耗数据，包括不加铜层及添加不同厚度铜层等条件下的涡流损耗情况。数据源自浙江大学开展的车用燃料电池空压机研发项目，旨在为相关领域提供分析依据。
