城市高负荷密集区配电网柔性互联和直流增容改造典型场景基础数据

城市高负荷密集区配电网柔性互联典型和直流增容改造场景基础数据包含了：1）典型柔性互联场景：“桂花—桥南线”两供一备馈线组的电网拓扑接线图，线路导线截面、额定容量、实际负荷数据等信息。2）直流增容改造典型场景：唐淇Ⅰ、Ⅱ线的电网拓扑接线图，线路导线截面、额定容量、实际负荷数据等信息。采集信息来源于电网公司实际规划和运行数据，具备真实性和有效性。数据格式为.pdf，文件大小为399KB。

Basic Dataset for Typical Flexible Interconnection and DC Capacity Upgrade Retrofit Scenarios of Distribution Networks in Urban High-Load Dense Areas contains the following contents:
1. Typical flexible interconnection scenarios: Grid topology wiring diagrams of the "Guihua-Qiaonan Line" two-supply-one-backup feeder group, along with information such as line conductor cross-sectional area, rated capacity, and actual load data.
2. Typical DC capacity upgrade retrofit scenarios: Grid topology wiring diagrams of the Tangqi I and II Lines, along with information such as line conductor cross-sectional area, rated capacity, and actual load data.
The collected data is sourced from the actual planning and operational data of power grid companies, ensuring its authenticity and validity. All data is stored in .pdf format with a file size of 399 KB.

搜集汇总

背景与挑战

背景概述

该数据集提供了城市高负荷密集区配电网柔性互联和直流增容改造的典型场景基础数据，包括'桂花—桥南线'馈线组和唐淇Ⅰ、Ⅱ线的电网拓扑、线路截面、额定容量及实际负荷信息。数据源自电网公司实际规划与运行，以PDF格式呈现，具备真实性和有效性。
