驱动器双脉冲测试平台数据集

本数据集收集了2022年7月至2025年8月期间高压大功率可关断器件双脉冲试验平台试制产生的设计和测试数据。双脉冲试验平台试制以支持柔性直流阀串和功率模块整机测试为目的，具备10kV/5kA的测试能力。试验平台设计开展了高压可调直流电源系统、直流电容、可调电抗器、控制系统、测量系统、液体加热系统、上位机系统的的选型设计，通过一系列试验检验了所设计平台的试验能力，试验平台可准确获取待测功率模块的特征参数，方便快捷的对功率器件和驱动电路的开关特性、开关损耗、安全工作区间、母排杂散电感进行测试和验证，可用于采用自研驱动芯片的功率模块的试制。

This dataset collects design and test data generated during the prototyping of a double-pulse test platform for high-voltage high-power turn-off devices, spanning from July 2022 to August 2025. This double-pulse test platform is developed to support full-unit testing of flexible DC valve strings and power modules, with a testing capability of 10kV/5kA. The platform design covers the selection and design of high-voltage adjustable DC power supply systems, DC capacitors, adjustable reactors, control systems, measurement systems, liquid heating systems, and host computer systems. A series of tests were conducted to verify the test capability of the designed platform, which can accurately obtain the characteristic parameters of power modules under test. It can conveniently and efficiently test and verify the switching characteristics, switching losses, safe operating area, and stray inductance of busbars for power devices and drive circuits, and is applicable to the prototyping of power modules adopting self-developed driver chips.

搜集汇总

背景与挑战

背景概述

该数据集收录了2022年7月至2025年8月间高压大功率可关断器件双脉冲试验平台的设计与测试数据，平台测试能力达10kV/5kA，旨在支持柔性直流阀串和功率模块整机测试。它可用于准确获取功率模块特征参数，并对功率器件和驱动电路的开关特性、损耗及安全性进行验证。
