1. Solution Introduction
The AR remote collaboration subsystem consists of modules such as audio and video service, AR glasses-side APP, enterprise-level PC application, and mobile APP (Android). It builds a technical channel for remote collaboration between on-site staff and back-end command centers and experts through forms such as audio-video calls, screen sharing, screenshot annotation, and collaborative whiteboard.

2. System Function Introduction
The AR remote collaboration subsystem consists of modules such as audio and video service, AR glasses-side APP, enterprise-level PC application, and mobile APP (Android). It builds a technical channel for remote collaboration between on-site staff and back-end command centers and experts through forms such as audio-video calls, screen sharing, screenshot annotation, and collaborative whiteboard.

3. Application Scenarios
It covers effective coverage of various application scenarios: equipment remote operation and maintenance. When the production line encounters an emergency failure, it can be quickly located and resolved remotely without waiting for experts to arrive on site; supplier remote support, suppliers can support multiple factories around the world at the same time to assist in resolving emergency equipment failures; remote training, remote first-person hands-on training and learning sharing, helping enterprises to cultivate talents quickly at low cost.

4. Functional Advantages
The core advantage of the AR remote collaboration system is that it can share first-person perspective screens with multiple parties, supporting various scenarios such as one-to-many, many-to-one, and many-to-many. It supports transmitting multiple types of files during communication, including documents, images, messages, etc. Remote users can pause the communication screen with one click or perform real-time annotation directly on the screen, and the guidance results will be synchronously displayed in the field of view of on-site users.

5. Function Usage Instructions
1. Real-time Remote Communication
The real-time remote communication function includes two-way audio and video channels.
2. Two-way Audio Channel
Provides high-quality real-time audio transmission services, realizing a new type of communication method between front-end and back-end users. On-site personnel can receive assistance from remote experts and complete work under the guidance of experts.
3. Two-way Video Channel
Provides high-definition real-time video transmission services, realizing a new type of communication method between front-end and back-end users. On-site personnel can receive assistance from remote experts and complete work under the guidance of experts.
4. Account Management
Add an AR remote collaboration account management module on the cloud VR management platform, supporting operations such as account addition, editing, and deletion. It can conduct authentication based on company name and account password, generate remote collaboration account QR codes, support copying to the clipboard for sharing and scanning to log in, and support refreshing and updating QR codes.
5. AR Glasses-side APP
5.1 Smart Network Configuration
Perform Wi-Fi authentication via a fixed web address (if Wi-Fi access is required), and generate a QR code for AR glasses to scan for smart network configuration.
5.2 Remote Collaboration Authentication and Login
Scan the account QR code with AR glasses to directly log in to the remote collaboration system, avoiding the inconvenience of manually entering and selecting account passwords.
5.3 Personnel List
View personnel list information, offline/online status and other information in AR glasses, and can designate personnel to initiate and answer calls.
5.4 Screen Sharing Collaboration
After the collaboration request is connected, the AR glasses will share the camera screen in real-time to mobile or PC users, and voice calls can be conducted.
5.5 Screenshot Annotation
After the user initiates a screenshot annotation instruction on the mobile phone or PC, the screenshot can be annotated. After the annotation is completed, it will be sent to the AR glasses end. At this time, the AR glasses will receive the complete screenshot annotation screen and support viewing.
5.6 Collaborative Whiteboard
After the mobile or PC user initiates a remote whiteboard instruction, the AR glasses can view the annotation, doodling and other content in the remote whiteboard in real-time.
5.7 Remote Screen Sharing
After the mobile or PC user initiates a remote screen sharing instruction, the AR glasses can view the remote screen content (text, images, PDF, video, etc.) sharing screen in real-time.
5.8 Collaborative Video Recording
All captured and returned audio and video, photo data and text messages will be automatically stored and archived by date, which can be retrieved and played back at any time, and a rolling storage mechanism is allowed to be set.
6. Enterprise-level PC Application
6.1 Personnel Account
Enterprise accounts are divided into two categories: administrators and regular personnel. Administrators can perform operations such as adding, editing, deleting, and grouping regular personnel accounts.
6.2 Permission Allocation
Supports flexible configuration of function module permissions, and can allocate corresponding permissions according to account roles.
6.3 Remote Collaboration Authentication and Login
The PC application logs in to the remote collaboration system via account and password.
6.4 Personnel Management
Retrieve personnel list information, offline/online status and other information from the server, and initiate and answer calls through the personnel list.
6.5 Screen Sharing
After the collaboration request is connected, a real-time audio and video channel is established, and the real-time camera screen of the glasses end is displayed on the PC, and voice calls can be conducted.
6.6 Invite Consultation
Supports inviting other experts to join the video consultation.
6.7 Screenshot Annotation
Initiate a screenshot annotation instruction by clicking the screenshot button, annotate on the screenshot screen and send it to the AR glasses end.
6.8 Collaborative Whiteboard
Click the whiteboard button to open the whiteboard, perform annotation, doodling and other operations on the whiteboard and send it to the glasses end.
6.9 Remote Screen Sharing
Click the screen share button to share the screen content (text, images, PDF, video, etc.) to the glasses end.
7. Mobile APP (Android)
7.1 Remote Collaboration Authentication and Login
The mobile APP logs in to the remote collaboration system via account and password.
7.2 Personnel Management
The mobile terminal retrieves personnel list information, offline/online status and other information from the server, and can initiate and answer calls through the personnel list.
7.3 Screen Sharing
After the collaboration request is connected, the collaboration end will display the real-time camera screen of the on-site glasses end, and voice calls can be conducted.
7.4 Invite Consultation
Invite other experts to join the video consultation on the mobile terminal.
7.5 Screenshot Annotation
The mobile terminal initiates a screenshot annotation instruction, and on-site personnel can annotate on the screenshot screen and send it to the glasses end. The glasses end personnel can view the screenshot annotation screen.
7.6 Collaborative Whiteboard
Initiate a remote whiteboard instruction on the mobile terminal, perform annotation, doodling and other operations on the whiteboard and send it to the glasses end.
7.7 Remote Screen Sharing
Initiate a remote screen sharing instruction on the mobile terminal, and share the screen content (text, images, PDF, video, etc.) to the glasses end.
