钢筋焊接力学性能检测数据

该检测数据适用于钢筋的质量进行评估的有力工具。完全符合相关规范所要求的试验流程的应用可以给出与标准相符的结论，提供了可靠性和可重复性的结果，从而有助于实现项目的成功完成和建设安全。依据JGJ/T27-2014《钢筋焊接接头试验方法标准》，钢筋牌号为HRB400B公称直径在6~50mm间的焊接接头极限抗拉强度标准值为≥540MPa。根据JGJ18-2012《钢筋焊接及验收规程》，检测机械连接接头单向拉伸性能，使用液压式万能试验机WES-600B（液压式万能试验机WE-1000B）仪器测得3个试件在钢筋拉断状态下的极限荷载值，计算得出三次极限抗拉强度实测值，计算公式为：极限抗拉强度实测值=极限荷载值/（π*（公称直径/2）^2）。比较极限抗拉强度实测值与极限抗拉强度标准值，若三次极限抗拉强度实测值均大于等于极限抗拉强度标准值，则接头单向拉伸性能符合要求；反之，若有任意一次极限抗拉强度实测值小于极限抗拉强度标准值，则须再抽区6个试件进行复检。判定公式如下：F(x)=IF(AND(极限抗拉强度实测值1>极限抗拉强度标准值,极限抗拉强度实测值2>极限抗拉强度标准值,极限抗拉强度实测值3>极限抗拉强度标准值),"合格",须复检)。

This test dataset is a powerful tool for evaluating the quality of steel bars. Strictly following the test procedures specified in relevant codes can yield conclusions consistent with standards, providing reliable and repeatable results, thereby contributing to the successful completion of projects and ensuring construction safety. According to JGJ/T27-2014 Standard for Test Methods of Welded Joints of Reinforcing Bars, the standard value of ultimate tensile strength for welded joints with steel bar grade HRB400B and nominal diameter ranging from 6 mm to 50 mm is ≥540 MPa. Per JGJ18-2012 Code for Welding and Acceptance of Reinforcing Bars, when testing the uniaxial tensile performance of mechanical connection joints, three specimens are tested using hydraulic universal testing machines WES-600B (or WE-1000B) to obtain the ultimate load values when the steel bars fracture. Three measured ultimate tensile strength values are calculated with the formula: Measured Ultimate Tensile Strength = Ultimate Load / (π*(Nominal Diameter/2)²). Compare the measured ultimate tensile strength values with the standard ultimate tensile strength value: if all three measured ultimate tensile strength values are greater than or equal to the standard value, the uniaxial tensile performance of the joint meets the requirements; otherwise, if any one of the three measured values is less than the standard value, an additional 6 specimens shall be sampled for retesting. The judgment formula is as follows: F(x)=IF(AND(Measured Ultimate Tensile Strength 1 ≥ Standard Ultimate Tensile Strength, Measured Ultimate Tensile Strength 2 ≥ Standard Ultimate Tensile Strength, Measured Ultimate Tensile Strength 3 ≥ Standard Ultimate Tensile Strength), "Qualified", "Re-test Required").

搜集汇总

数据集介绍

特点

该数据集包含75条钢筋焊接力学性能检测数据，记录了试样编号、工程部位、钢筋牌号、焊接方法、公称直径、拉伸荷载和强度实测值等关键信息。数据适用于钢筋质量评估，依据JGJ/T27-2014和JGJ18-2012标准进行检测和判定，完全符合相关规范要求，具有可靠性和可重复性。
