XDE120轮毂驱动单元集成设计模型

针对120吨级矿用自卸车轮毂驱动的大扭矩高承载（输出扭矩0.29×10^6 Nm，承重210 T）及体积空间（齿圈最大径向840mm）受限等特点，轮毂驱动单元设计采用集成化设计方法，建立模型包含电机结构：电机定子，转子，电机壳体，电机轴等,减速机结构：结构件参数、行星排参数、花键参数、轴承类型、密封类型；根据轮毂驱动在主机上的应用，设置输入输出、径向力等信息，并明确行星齿轮传动与电机、机架、轮胎及制动器连接界面约束关系及特征状态空间。在有限元中，对机架、轮毂、壳体等部位进行多目标拓扑优化分析，机架最大应力降低为227Mpa，重量减轻5%左右。在多工况复合载荷谱下，轴承寿命不低于50000小时，齿轮、轴等部件的安全系数大于1，实现驱动行星齿轮传动系统集成设计。 数据量32.3MBAiming at the characteristics of high torque and high load carrying capacity (output torque: 0.29×10^6 Nm, load capacity: 210 T) and limited installation space (maximum radial dimension of gear ring: 840 mm) of the hub drive for 120-ton mining dump trucks, the hub drive unit adopts an integrated design method. The established model covers the motor structure including motor stator, rotor, motor housing, motor shaft, etc., as well as the reducer structure including structural component parameters, planetary gear set parameters, spline parameters, bearing types and seal types. Based on the on-board application of the hub drive, parameters such as input/output and radial force are configured, and the connection interface constraint relationships and characteristic state spaces between the planetary gear transmission and the motor, frame, tire and brake are clarified. In finite element analysis, multi-objective topology optimization is conducted on components such as the frame, hub and housing, with the maximum stress of the frame reduced to 227 MPa and its weight reduced by approximately 5%. Under the composite load spectrum of multiple working conditions, the bearing life is no less than 50000 hours, and the safety factors of components such as gears and shafts are greater than 1, realizing the integrated design of the drive planetary gear transmission system. Data volume: 32.3 MB

搜集汇总

背景与挑战

背景概述

该数据集提供了XDE120轮毂驱动单元的集成设计模型，针对120吨级矿用自卸车的大扭矩高承载需求，采用集成化方法构建了包含电机和减速机结构的模型，并通过多目标拓扑优化分析实现了系统性能提升。模型数据量约为32.3MB，涵盖了设计参数、约束关系及优化结果，支持轮毂驱动系统的集成设计与分析。
