Study on optimization effect of south roof curve of Chinese solar greenhouse

To maximize the use of solar energy and increase the utilization area of Chinese solar greenhouse (CSG) land, a solar greenhouse radiation model was established based on previous studies, combining with the law of solar movement, meteorological data, and optical properties of materials. The model is verified by selecting the measured data of typical sunny days. The results show that the optimization of the south roof curve of the greenhouse can not only increase the land-use area in the greenhouse but also increase the solar energy captured by the solar greenhouse. And the CSG in the greenhouse, the land-use area in the greenhouse increased to 42 m2, the lighting rate of the south roof, and the lighting rate of the ground increased 15.2% and 0.78% respectively. The amount of interception in the back wall of the greenhouse was reduced by 0.67%, and that in the greenhouse was increased by 2.22%. The optimal structure CSG in Shenyang (span 9 m) is the optimal shoulder height position, obta..., , , To maximize the use of solar energy and increase the utilization area of Chinese solar greenhouse (CSG) land, a solar greenhouse radiation model was established based on previous studies, combining with the law of solar movement, meteorological data, and optical properties of materials. The model is verified by selecting the measured data of typical sunny days. The results show that the optimization of the south roof curve of the greenhouse can not only increase the land-use area in the greenhouse but also increase the solar energy captured by the solar greenhouse. And the CSG in the greenhouse, the land-use area in the greenhouse increased to 42 m2, the lighting rate of the south roof, and the lighting rate of the ground increased 15.2% and 0.78% respectively. The amount of interception in the back wall of the greenhouse was reduced by 0.67%, and that in the greenhouse was increased by 2.22%. The optimal structure CSG in Shenyang (span 9 m) is the optimal shoulder height position, obta...

为最大化太阳能利用效率、提升中国日光温室（Chinese solar greenhouse, CSG）的土地利用面积，本研究结合前人研究成果，融合太阳运行规律、气象数据与材料光学特性，构建了日光温室辐射模型。通过选取典型晴天的实测数据对该模型进行验证，结果表明：优化温室南屋面曲线不仅可提升温室内土地利用面积，还可增加日光温室捕获的太阳能。以沈阳地区跨度9米的中国日光温室为例，优化后温室内土地利用面积增至42平方米，南屋面采光率与地面采光率分别提升15.2%与0.78%；温室后墙截获太阳能减少0.67%，温室内截获太阳能增加2.22%。沈阳地区跨度9米的最优结构中国日光温室的最优肩高位置为……
