加工装备空间误差补偿数据集

在开展机床精度自愈技术研究过程中，使用Renishaw XM60激光干涉仪，按照ISO-230标准中的操作规范，测量了华中数控HNC8、Siemens、Fanuc、Mazak四种数控系统各1台加工中心的几何误差数据，数据项包括机床X、Y、Z三轴的1项定位误差、2项直线度误差、3项角度误差，以及任意两轴之间的角度误差，共计21项几何误差数据。数据量175KB。

During the research on machine tool accuracy self-healing technology, geometric error data was measured for one machining center equipped with each of the four CNC systems: Huazhong CNC HNC8, Siemens, Fanuc, and Mazak, using a Renishaw XM60 laser interferometer in accordance with the operational specifications stipulated in the ISO-230 standard. The measured data items include 1 positional error, 2 straightness errors, and 3 angular errors for each of the X, Y, and Z axes of the machine tool, as well as angular errors between any two axes, totaling 21 sets of geometric error data. The total data size is 175 KB.

搜集汇总

背景与挑战

背景概述

该数据集聚焦于加工装备的空间误差补偿，包含来自四种主流数控系统（华中数控HNC8、Siemens、Fanuc、Mazak）加工中心的几何误差测量数据，涵盖21项具体误差类型，严格遵循ISO-230标准。数据来源于国家重点研发计划项目，旨在支持机床精度自愈和智能工厂集成技术的研究与应用。
