PCB板PIN脚高度检测精度分析数据

高精度3D视觉检测系统软硬件用于对汽车配件PCB板PIN脚高度的检测，配准精度高，成像质量好，轮廓基本完整，细节纹理清晰，本检测数据便于后续点云算法及软件处理，也可以为客户使用高精度3D视觉检测系统软硬件对汽车配件PCB板PIN脚高度检测的精确性提供参考，为客户购买提供参考和技术支撑。1.数据采于企业内部产品检测数据; 2.利用高精度3D视觉检测系统软硬件对汽车配件PCB板PIN脚高度进行检测获得相关数据，具体为：定位好PCB位置，利用Ref regions校平PCB，以PIN脚点检测PIN脚高度。 3数据处理:通过对测量区域重复测量得到PIN脚高度最大值和PIN脚高度最小值，两者相减即可得到此点的重复测量精度。4、数据应用：为企业生产加工工艺提升和产品质量检测提供数据支持。The hardware and software of the high-precision 3D visual inspection system are designed for detecting the pin height of PCBs for automotive parts. This system features high registration accuracy, excellent imaging quality, basically complete contours, and clear detailed textures. The collected inspection data is conducive to subsequent point cloud algorithm and software processing, and can provide reference for the accuracy of pin height detection of automotive part PCBs when customers use the high-precision 3D visual inspection system hardware and software, as well as offer reference and technical support for customers' purchasing decisions. 1. The data is sourced from the enterprise's internal product inspection datasets. 2. Relevant data is acquired by detecting the pin height of PCBs for automotive parts using the hardware and software of the high-precision 3D visual inspection system. The specific steps are: first locate the PCB position, then level the PCB using Ref regions, and detect the pin height via the pin points. 3. Data processing: The maximum and minimum pin heights are obtained through repeated measurements of the measurement area, and the repeated measurement accuracy of this point can be calculated by subtracting the two values. 4. Data application: Provide data support for enterprises to improve production and processing technologies and conduct product quality inspections.

搜集汇总

数据集介绍

特点

该数据集包含523条记录，每年更新一次，主要用于汽车配件PCB板PIN脚高度的精确检测。数据涵盖了环境温度、湿度、PCB尺寸、3D设备参数及PIN脚高度等关键信息，适用于高精度3D视觉检测系统的性能评估和优化。
