Lamella facade system and use thereof

The present invention relates to a lamella front surface system ( 1)， comprising at least one lamella (2)， at least two metal mounting elements (3) each having a mounting axis， configured to be attached to a support (4)， e.g. the face of a building， each of the metal mounting elements comprising mounting side (6) abutting the face in its mounted position， an interfacing side (7) arranged opposite the mounting side， the interfacing side comprising attachment means (8)， wherein the lamella front surface system further comprises a fixation element (5) having a longitudinal extension (FA) and having a body (9) having a first side (10) comprising interfacing means (12， 13) configured to be connected with the attachment means， and a second side (11) configured to support the lamella in a position which is substantially perpendicular to the mounting axis of the metal mounting elements， and wherein the lamella is made from a non-metal material. The present invention also relates to use of the lamella front surface system according to the present invention.本发明涉及一种板条外立面系统（lamella front surface system，标号1），其包括至少一块板条（lamella，标号2）、至少两个各带有安装轴线（mounting axis）的金属安装构件（metal mounting elements，标号3）；该金属安装构件配置为可安装至支撑体（support，标号4），例如建筑外立面。每个金属安装构件包含在安装状态下贴靠该支撑体面的安装侧（mounting side，标号6），以及与该安装侧相对设置的对接侧（interfacing side，标号7），该对接侧设有连接结构（attachment means，标号8）。本板条外立面系统还包括一具有纵向延伸方向（longitudinal extension，FA）的固定构件（fixation element，标号5），该固定构件具有主体（body，标号9）；主体的第一侧（first side，标号10）设有配置为与上述连接结构相连的对接结构（interfacing means，标号12、13），第二侧（second side，标号11）配置为以基本垂直于金属安装构件安装轴线的位置支撑该板条；且该板条由非金属材料（non-metal material）制成。本发明还涉及本发明所述板条外立面系统的应用。

搜集汇总

背景与挑战

背景概述

该数据集涉及一项名为'Lamella facade system and use thereof'的专利技术，主要描述了一种包含非金属材料百叶窗的立面系统及其应用。数据集包含专利的详细描述、发布时间、访问统计以及相关的数据服务元信息，属于植物学学科的科学数据资源。
