中压并网逆变器并网电流THDi测试数据集

中压并网逆变器并网电压测试数据集主要面向基于模块化技术的新型光伏中压发电装备的开发和试验研究中的并网电流谐波含量验证需求而建设。基于待测样机、中压工程试验平台和WT3000E功率分析仪进行了相关试验并得到相关数据。本数据集主要记录了不同运行功率下的三相并网电流各次谐波测试值，数据量51KB。This medium-voltage grid-connected inverter grid-connected voltage test dataset was constructed primarily to address the requirement for verifying grid-connected current harmonic content during the development and experimental research of novel photovoltaic medium-voltage power generation equipment based on modular technology. Relevant experiments were conducted using the prototype under test, the medium-voltage engineering test platform, and the WT3000E power analyzer, and the corresponding experimental data were obtained. This dataset mainly records the test values of each-order harmonics of the three-phase grid-connected current under different operating powers, with a total data size of 51 KB.

搜集汇总

背景与挑战

背景概述

该数据集专注于中压并网逆变器的并网电流谐波测试，旨在支持新型光伏中压发电装备的开发和试验研究，验证电流谐波含量。数据集包含在不同运行功率下测量的三相并网电流各次谐波值，数据量较小为51KB，来源于阳光电源股份有限公司基于实际试验平台和功率分析仪采集的数据，属于国家重点研发计划项目成果。
