400G光模块PVT测试数据

本数据是400G 模块的PVT测试数据，包含使用万用表测试各电源在拉偏条件下的输出电压，使用实时示波器测试各电源在拉偏条件下的纹波，使用实时示波器测试各电源的上电时序，使用实时示波器测试各通讯时序，使用实时示波器测试各信号波形，使用光示波器及BERT测试模块光性能，使用功率计测试模块的DDM精度，使用稳压电源及BERT测试模块

This dataset consists of PVT test data for 400G modules. The included test contents are as follows: output voltages of each power supply under bias stress conditions measured by a multimeter; ripple waveforms of each power supply under bias stress conditions, power-on timing sequences of each power supply, communication timing sequences and individual signal waveforms, all measured by a real-time oscilloscope; optical performance of the modules tested by an optical oscilloscope and BERT test modules; DDM (Digital Diagnostic Monitoring) accuracy of the modules measured by a power meter; and tests conducted using a regulated power supply and BERT test modules.

搜集汇总

背景与挑战

背景概述

该数据集提供了400G光模块的PVT测试数据，包含电源输出电压、纹波、时序、信号波形及光性能等多项测试结果。数据由朱虎整理，数据量约为431.61KB，来源于国家重点研发计划项目。
