光模块传输总容量测试数据

光传输总量用于证明1Tb/s模块的光信号传输能力大于1Tb/s，测试主要来源于课题任务书中支撑关于1Tb/s相干光收发模块指标2.2-光模块传输总量大于1Tb/s的要求；数据是理论计算或在实验室条件下通过任意波形发生器，高速实时示波器、可调光源、稳压电源、可调窄线宽激光器等科学仪器采集处理得到的；数据包括了波特率为76Gbaud，调制格式为DP-16QAM的发射信号码流和两个载波分别25次实时采样的原始数据，数据量1.81GB。The total optical transmission capacity is used to verify that the optical signal transmission capability of the 1Tb/s optical module exceeds 1Tb/s. The testing primarily supports the requirement specified in Requirement Item 2.2 of the project task specification for 1Tb/s coherent optical transceiver modules, which mandates that the total transmission capacity of the optical module exceeds 1Tb/s. The data is acquired via theoretical calculations or collected and processed using scientific instruments including arbitrary waveform generators, high-speed real-time oscilloscopes, tunable light sources, regulated power supplies, and tunable narrow-linewidth lasers under laboratory conditions. The dataset comprises raw transmitted signal bitstream with a baud rate of 76Gbaud and DP-16QAM modulation format, as well as 25-time real-time sampling data for each of the two carriers, with a total data volume of 1.81 GB.

搜集汇总

背景与挑战

背景概述

该数据集用于验证1Tb/s光模块的传输总容量大于1Tb/s，基于课题任务书要求，通过理论计算和实验室仪器采集得到。数据包含波特率76Gbaud、调制格式DP-16QAM的发射信号码流及两个载波的实时采样原始数据，总数据量为1.81GB。
